QUBE 4CH Mobile HDTVI 720P

P4,858.33 / Month for 6 Months. Pls call our Stores to inquire about qualified credit card.

Features:

• 4 -ch 720P HD TVI recording

• 2pcs 2.5” HDDs / SSD,1 SD/SDHC

• Build-in G-sensor

• 3rd G patent HDD shock absorption case

Specification:

Video/Audio Input

• Audio Input: | 4-ch

• Video Compression: | H.264

• Analog Video Input: | 4-ch

• Video Input Interface: | Aviation plug (1.0 Vp-p, 75 Ω), PAL/NTSC self-adaptive

• Audio Compression: | G.711

• Audio Input Interface: | Aviation Interface (linear electrical level, 1 kΩ)

• Two-way Audio: | 1 Aviation Interface (Linear electrical level, 1KΩ)

Video/Audio Output

• Video output: | 2-ch CVBS video output, aviation plug (1.0 Vp-p , 75 Ω)

• Resolution: PAL: 704×576, NTSC: 704×480

• VGA Output: | 1-ch, resolution:

• 1920×1080P/60Hz,1280×1024/60Hz,1280×720/60Hz, 1024×768/60Hz

• CVBS Output: | 1-ch aviation plug (1.0 Vp-p, 75 Ω) and 1-ch RS-422; PAL: 704 × 576, NTSC: 704 × 480

• Recording resolution: | 720P/4CIF/DCIF/2CIF/CIF/QCIF

• Stream Type: | Video/Video&Audio

• Dual Stream: | Support

Hard Disk Driver

• Interface Type: | 2 2.5-inch SATA interfaces for Pluggable HDD /SSD disks

• Capacity: | support 2.5” SATA HDD/SSD

• Data Backup: | Backup by pluggable HDD /eSATA /USB devices

Wireless Transmission

• GPS: | Built-in high-sensitivity GPS chip

External Interface

• SD Card Interface: | 1 standard SD/SDHC slot

• Network Interface: | 1 RJ45 10M/100M adaptive Ethernet Interface

• 3G antenna interface: | SMA interfaces for 2 3G antennas, 1 WIFI antennas and 1 GPS antenna

• USB Interface: | 2 USB 2.0 Interfaces

• Alarm Input: | 3-ch high/low-level signal input

• Alarm Output: | 2-ch

• Remote Control: | Special remote controller/IR remote controller

• GPS: | Built-in GPS Module, 1 antenna, SMA interface

• Control mode: | IR,WEB,Control Client

• Driving Information Collection: | 4-ch high/low-level signal input, 1-ch pulse signal input(reserved)

General

• Power Input: | 9 to 32 VDC;

• Power Output: | 12 VDC/1 A, 5 VDC/1 A

• Operating System: | Embedded Linux Operating System

• Power Off Delay: | support

• Schedule On/Off: | support

• Consumption: | ≤ 20 W

• Working Temperature: | -25º C to +70º C (-13º F to 158º F)

• Working Humidity: | 10% to 90%

• Dimensions: | 202 × 85.5 × 253 (7.95 × 3.37 × 9.96")

• Weight: | Approx. 3 kg (6.61 lb)
