QUBE FISHEYE 4MEGAPIXEL PANORAMIC 180 DEGREE

More IP Deluxe Dome Camera Options, Click here

P1,112.82 / Month for 6 Months. Pls call our Stores to inquire about qualified credit card.

Daytime Demo:

Specification

• Model Fisheye

Camera

• Image Sensor 1/3” 4Megapixel progressive scan CMOS
• Effective Pixels 2592(H)x1520(V)
• Scanning System Progressive
• Electronic Shutter Speed Auto/Manual 1/3(4)~1/10000
• Min. Illumination 0.01lux/F2.0(color) ,0.001Lux@F2.0(B/W)
• S/N Ratio More than 50dB
• Video Output N/A

Camera Features

• Max. IR LEDs Length N/A
• Day/Night Auto(Electronic)/Color/B/W
• Backlight Compensation BLC/HLC/DWDR
• White Balance Auto/Manual
• Gain Control Auto/Manual
• Noise Reduction 3D
• Privacy Masking Up to 4 areas

Lens

• Focal Length 1.18mm
• Max Aperture F2.0
• Focus Control Manual
• Angle of View H:180°
• Lens Type Fixed lens
• Mount Type Board-in Type

Video

• Compression H.264/ MJPEG
• Resolution:4M(2592×1520)/3M(2048×1520)/UXGA(1600×1200)/1.3M(1280×960)/720P(1280×720)/D1(704×576/704×480)/CIF(352×288/352×240)
• Frame Rate Main Stream 4M(1~15fps)/ 3M (1 ~ 25/30fps)
• Sub Stream D1/CIF(1 ~ 25/30fps)
• Bit Rate H.264: 20K ~ 8192Kbps

Audio

• Compression G.711a/G.711u/PCM
• Interface 1/1 channel In/Out(Built in Mic)
• Network
• Ethernet RJ-45 (10/100Base-T)
• Wi-Fi N/A
• Protocol IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour
• Compatibility ONVIF,PSIA,CGI
• Max. User Access 20 users
• Smart Phone iPhone, iPad, Android, Windows Phone

Auxiliary Interface

• Memory Slot Micro SD, Max 64GB
• RS485 N/A
• Alarm 1/1 channel In/Out
• PIR Sensor Range N/A

General

• Power Supply DC12V,PoE
• Power Consumption Max 6W
• Working Environment -30°C~+60°C, Less than 95% RH
• Ingress Protection N/A
• Vandal Resistance IK10
• Dimensions Φ110mm×54mm / 4.3" x 2" inches
• Weight 0.25kg
