QUBE HI8-TVI DVR 8CH HDTVI 3MP eSATA 4in1, Support TVI/AHD/IP/Analog

More TVR Recorder Options, Click here

P2455.49 / Month for 6 Months. Pls call our Stores to inquire about qualified credit card.

Features:

• H.264 ,H.264+& Dual-stream video compression

• Support HD-TVI, IPC, AHD and analog cameras with adaptive access (4 in 1)

• Support Cloud storage(One Drive, Google Drive or Drop Box)

• Up to 3 MP resolution for recording of the first channel

• VGA output at up to 1920×1080P resolution,HDMI output at up to 4K(3840x2160) resolution

• Long transmission distance over coax cable

• Up to 8-ch synchronous playback at 1080p resolution

• playback at up to 256X speed.

• Support POE functions.

Specification:

Video/Audio Input

• Audio Input: | 4-ch

• Video Compression: | H.264,H.264+

• Analog and HD-TVI video input: | 8-ch,BNC interface (1.0Vp-p, 75 Ω)connection

• Supported camera types: | Support HDTVI input: 3MP, 1080p/25Hz, 1080p/30Hz, 720p/25Hz, 720p/30Hz, 720P/50Hz, 720p/60Hz

Note: The 3 MP signal input is only available for the first 2 channel

• Video Input Interface: | BNC (1.0 Vp-p, 75Ω)

• Audio Compression: | G.711u

• Audio Input Interface: | 4-ch, RCA (2.0 Vp-p, 1 KΩ)

• Two-way Audio: | 1-ch, RCA (2.0 Vp-p, 1 KΩ) (using audio input)

Video/Audio Output

• CVBS Output: | 1-ch,BNC(1.0Vp-p,75Ω),resolution:PAL:704x576,NTSC:704x480

• HDMI/VGA Output: | HDMI: 1-ch,4K(3840×2160)/30Hz,2K(2560×1440)/60Hz, 1920×1080/60Hz, 1280×1024/60Hz,1280×720/60Hz,1024 ×768/60Hz

• VGA:1-ch,2K(2560×1440)/60Hz,1920×1080/60Hz,1280×1024/60Hz,1280×720/60Hz,1024×768/60Hz

• Recording resolution: | When 1080p Lite mode not enabled: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF; When 1080p Lite mode enabled: 3 MP/1080p lite/720p/VGA/WD1/4CIF/CIF

Frame Rate: | Main stream:

• When 1080p Lite mode not enabled:
• For 3 MP stream access: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@12fps

• For 1080p stream access: 1080p/720p@12fps; VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)

• For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
• When 1080p Lite mode enabled:
• 3 MP/1080p lite/720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)

• Video Bit Rate: | 32 Kbps-6 Mbps

• Stream Type: | Video/Video&Audio

• Two-way Audio: | 1-ch, RCA (2.0 Vp-p, 1 kΩ) (using the audio input)

• Audio Output: | 1-ch RCA(Linear, 1kΩ)

• Audio Bit Rate: | 64kbps

• Dual Stream: | Support

• Playback Resolution: | 3 MP/1080p/720p/VGA/WD1/4CIF/CIF

• Synchronous Playback: | 8-ch

Network management

• Remote connections: | 128

• Network protocols: | TCP/IP, PPPoE, DHCP, Hik-connect Cloud P2P,DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS,ONVIF

Hard Disk Driver

• Interface Type: | 4 SATA Interfaces

• Capacity: | Up to 8 TB capacity for each disk

External Interface

• Network Interface: | 1; 10M / 100M / 1000M self-adaptive Ethernet interface

• USB Interface: | 2 USB 2.0 Interface on the front panel
