QUBE K32-TVR DVR 32CH HDTVI 4MP 5in1, Support TVI/CVI/AHD/IP/Analog

More TVR Recorder Options, Click here

P5123.15 / Month for 6 Months. Pls call our Stores to inquire about qualified credit card.

Features:

• Support HD-TVI, CVI, AHD, Analog, IP Camera (5 in 1)

• Up to 4MP resolution for recording
• HDMI output at up to 4K (3840 × 2160) resolution

• Long distance transmission over UTP and coaxial cable: max. 800m for 1080p and 1200m for 720p HDTVI signal
• Supports POS triggered recording and POS information overlay

Specification:

Video/Audio Input

• Audio Input: | 4-ch

• Video Compression: | H.265+/H.265/H.264+/H.264

• Analog Video Input: | 32-ch,BNC interface (1.0Vp-p, 75 Ω)connection

• Analog and HD-TVI video input: | 32-ch

• Supported camera types: | Support HDTVI input: 4MP,3 MP, 1080p/25Hz, 1080p/30Hz, 720p/25Hz, 720p/30Hz, 720P/50Hz, 720p/60Hz
  Note: The 3 MP signal input is only available for channel 1/2/3/4.
  Support AHD input: 4MP,1080p/25Hz, 1080p/30Hz, 720p/25Hz, 720p/30Hz
  Support CVI input: 1080p25, 1080p30, 720p25, 720p30
  support CVBS input

• IP Video Input: | 8-ch(up to 40ch) Up to 6MP resolution

• Video Input Interface: | BNC (1.0 Vp-p, 75Ω)

• Audio Compression: | G.711u

• Audio Input Interface: | 4-ch, RCA (2.0 Vp-p, 1 KΩ)

• Two-way Audio: | 1-ch, RCA (2.0 Vp-p, 1 KΩ) (using audio input)

Video/Audio Output

• CVBS Output: 1-ch,BNC(1.0Vp-p,75Ω),resolution:PAL:704x576,NTSC:704x480

• HDMI: 1-ch,4K(3840×2160)/30Hz,2K(2560×1440)/60Hz, 1920×1080/60Hz, 1280×1024/60Hz,1280×720/60Hz,1024 ×768/60Hz
  VGA:1-ch,2K(2560×1440)/60Hz,1920×1080/60Hz,1280×1024/60Hz,1280×720/60Hz,1024×768/60Hz

• Recording resolution: | When 1080p Lite mode not enabled:
  4 MP lite/3 MP/1080p/1080p lite/720p/WD1/4CIF/VGA/CIF
  When 1080p Lite mode enabled:
  4 MP lite/3 MP/1080p lite/720p/720p lite/WD1/4CIF/VGA/CIF

• Frame Rate: | Main stream:
  When 1080p Lite mode not enabled:
  For 4 MP stream access: 4 MP lite@15fps; 1080p lite/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)
  For 3 MP stream access: 3 MP/1080p/720p/WD1/4CIF/VGA/CIF@15fps
  For 1080p stream access: 1080p/720p@15fps; 720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)
  For 720p stream access: 720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)
  When 1080p Lite mode enabled:
  For 4 MP stream access: 4 MP lite@15fps; 1080p lite/720p lite/WD1/4CIF/VGA/CIF@25fps (P)/30fps
  (N)
  For 3 MP stream access: 3 MP/1080p lite/720p lite/WD1/4CIF/VGA/CIF@15fps
  For 1080p stream access: 1080p lite/720p lite/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)
  For 720p stream access: 720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)

• Video Bit Rate: | 32 Kbps-6 Mbps
• Stream Type: Video/Video&Audio
• Two-way Audio: 1-ch, RCA (2.0 Vp-p, 1 kΩ) (independent)

• Audio Output: |1-ch RCA(Linear, 1kΩ)

• Dual Stream: | Support

• Playback Resolution: | 4MP/3MP/1080p/720p/VGA/WD1/4CIF/CIF/QVGA/QCIF

• Synchronous Playback: | 16-ch

• Network management

• Remote connections: | 128

• Network protocols: | TCP/IP, PPPoE, DHCP, Hik-connect Cloud P2P,DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP?, HTTPS,ONVIF

Hard Disk Driver

• Interface Type: | 4 SATA interfaces for 4 HDDs;

• Capacity: | Up to 8 TB capacity for each disk

• e-SATA Interface: | 1 eSATA interface

External Interface

• Network Interface: | 1; 10M / 100M / 1000M self-adaptive Ethernet interface

• USB Interface: | 2 USB 2.0 Interface on the front panel& 1 USB 3.0 Interface on the rear panel

• Alarm Input: | 16-ch

• Alarm Output: | 4-ch

General

• Power Supply: | 100 to 240 VAC, 47 to 63 Hz

• Consumption: | ≤ 45W(without hard disks)

• Working Temperature: | -10º C to +55º C (14º F to 131º F)

• Working Humidity: | 10% to 90%

• Dimensions: | 440 × 390 × 70 mm (17.3 × 15.4 × 2.8 inch)

• Weight: | ≤ 7 kg (15.4 lb)
