QUBE VERDIN D-MPDW30-W 3MP / 3~12MM / POE / MICRO SD

More IP Deluxe Dome Camera Options, Click here

Pls call our Stores to inquire about qualified credit card.

Daytime Demo:

Nighttime Demo:

Specification

• Model Qube D-MPDW30-W

Camera Features

• Max. IR LEDs Length: 20m
• Day/Night: Auto(ICR)/Color/B/W
• Backlight Compensation: BLC / HLC / WDR （100dB）
• White Balance: AUTO
• Gain Control: Auto/Manual
• Noise Reduction: 3D
• Privacy Masking: Up to 4 areas

Lens

• Focal Length: 3.3-12mm
• Max Aperture: F1.4
• Focus Control: Manual
• Angle of View: H: 91.2°(Wide)~25.5°(Tele)
• Lens Type: Manual / Auto Iris (DC)
• Mount Type: Board-in Type

Video

• Compression: H.264 / MJPEG
• Resolution: 3.0M(2048×1536) / 1080P(1920×1080) / 720P(1280×720) / D1(704×576) / CIF(352×288)
• Frame Rate: Main Stream: 3M(1~15fps)/1080P/720P(1 ~ 25/30fps) / Sub Stream: D1/CIF(1 ~ 25/30fps)
• Bit Rate: H.264: 32K ~ 8192Kbps, MJPEG: 32K ~ 24576Kbps

Audio

• Compression: G.711a / G.711u(64kbps) / PCM(128kbps)
• Interface: 1/1 channel In/Out

Network

• Ethernet: RJ-45 (10/100Base-T)
• Protocol: IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour
• ONVIF: ONVIF Ver. 2.0 ONVIF Profile S
• Max. User Access: 10 users
• Smart Phone: iPhone, iPad, Android, Windows Phone

Auxiliary Interface:

• Memory Slot: Micro SD, Max 32GB
• Alarm: 1/1 channel In/Out

General:

• Power Supply: DC12V(AC24 optional), PoE(802.3af)
• Power Consumption: 10W
• Working Environment: -25°C~+60°C, 10%~90%
• Protection Level: IK10 & IP66
• Dimensions: Φ5.9"×4.6"
• Weight: 1.25Kg
