Qube 16CH HDTVI / 3 in 1 / AUDIO / ALARM / up to 1.3MP "16CH-TVI"

More TVR Recorder Options, Click here

P1,148.34 / Month for 6 Months. Pls call our Stores to inquire about qualified credit card.

Features:

• H.264 & Dual-stream video compression

• Support HD-TVI, Analog, IP camera triple hybrid (3 in 1)

• Support both HD-TVI and analog cameras with adaptive access

• Full channel@ 720P resolution non real-time recording

• HDMI and VGA output at up to 1920×1080P resolution

• Long transmission distance over coax cable

• Support up to 16-ch synchronous playback

Specification

• Video/Audio Input
• Audio Input: | 4-ch
• Video Compression: | H.264
• Analog and HD-TVI video input: | 16-ch,BNC interface(1.0Vp-p,75Ω)
• Supported camera types: | 720p25,720p30,720p50,720p60,1080p25,1080p30,CVBS
• IP Video Input: | 2-ch 1080P
• Video Input Interface: | BNC (1.0 Vp-p, 75Ω)
• Audio Compression: | G.711u
• Audio Input Interface: | RCA (2.0 Vp-p, 1 kΩ)
• Two-way Audio: | 1-ch, RCA (2.0 Vp-p, 1 KΩ), (using the 1st channel of audio input)

• HDMI/VGA Output: | 1920 × 1080 / 60 Hz,1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz
• Recording resolution: | Main stream: 1080P / 720P / VGA / WD1 / 4CIF / CIF;Sub-stream: WD1(non-real-time) / 4CIF(non-real-time) / CIF / QCIF / QVGA
• Frame Rate: | Main stream: 1/16 fps ~ Real time frame rate
• Sub-stream: 1/16 fps ~ Real time frame rate
• Video Bit Rate: | 32 Kbps-10 Mbps
• Stream Type: | Video/Video&Audio
• Audio Output: | 1-ch RCA(Linear, 1kΩ)
• Audio Bit Rate: | 64kbps
• Dual Stream: | Support
• Playback Resolution: | 1080P / 720P / VGA / WD1 / 4CIF / CIF / QVGA / QCIF
• Synchronous Playback: | 16-ch

• Remote connections: | 128
• Network protocols: | TCP/IP, PPPoE, DHCP, EZVIZ Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS, iSCSI, UPnP™, HTTPS

• Interface Type: | 2 SATA Interfaces
• Capacity: | Up to 6 TB capacity for each disk

• Network Interface: | 1; 10M / 100M / 1000M self-adaptive Ethernet interface
• USB Interface: | 2 USB 2.0 Interfaces
• Serial Interface: | 1; standard RS-485 serial interface, half-duplex
• Alarm Input: | 16-ch
• Alarm Output: | 4-ch

• Power Supply: | 12V DC
• Consumption: | ≤ 45W(without hard disks)
• Working Temperature: | -10 ºC ~+55 ºC (14 ºF ~ 131 ºF)
• Working Humidity: | 10% ~ 90%
• Chassis: | 380mm 1U chassis
• Dimensions: | 380 × 290 × 48mm (15.0 × 11.4 × 1.9 inch)
• Weight: | ≤ 2Kg (4.4lb)(without hard disks)
