Qube 4CH HDCVR / 5 in 1 / AUDIO / 720P REAL-TIME PLAYBACK "4-7P-CVR-X"

More CVR Recorder Options, Click here

P547.67 / Month for 6 Months. Pls call our Stores to inquire about qualified credit card.

Features:

• 5 in 1 TVI/CVI/IP/AHD/Analog
• Support HDCVI/Analog/IP Video input
• H.264 dual-stream video compression
• All channel 720P realtime or 1080P non-realtime recording
• HDMI/VGA simultaneous video output
• 4channel synchronous realtime playback, GRID interface & smart search
• ONVIF Version 2.4 conformance
• 3D intelligent positioning with Qube PTZ dome camera
• Support 1 SATA HDD up to 4TB, 2 USB2.0
• Multiple network monitoring

Specification:

• Model 4-7P-CVR

• Main Processor Embedded processor
• Operating System Embedded LINUX

• Input 4 channel, BNC
• support Analog, CVI, IP camera (3 in 1)
• Standard Analog NTSC(525Line,60f/s),PAL(625Line,50f/s)
• HDCVI 1080P/720P HDCVI Camera
• IP 1080P/720P/D1/CIF IP Camera

• Input 1 channel, RCA
• Output 1 channel, RCA
• Two-way Talk Reuse audio input/output channel 1

• Interface 1 HDMI, 1 VGA
• Resolution 1920×1080, 1280×1024, 1280×720, 1024×768, 800×600
• Display Split 1/4
• Privacy Masking 4 rectangular zones (each camera)
• OSD Camera title, Time, Video loss, Camera lock, Motion detection, Recording

• Video/Audio Compression H.264/G.711
• Record Rate Main Stream: 1080P(1~15fps)/ 720P/960H/D1 (1~25/30fps)
• Extra Stream CIF/QCIF(1~25/30fps), D1(1~6/7fps)
• Bit Rate 96~4096Kb/s
• Record Mode Manual, Schedule(Regular(Continuous), MD), Stop
• Record Interval 1~60 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec

• Trigger Events Recording, PTZ, Tour, Alarm out, Video Push, Email, FTP, Snapshot,
• Buzzer & Screen tips
• Video Detection Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank
• Playback & Backup
• Sync Playback 1/4
• Search Mode Time/Date, MD & Exact search (accurate to second)
• Playback Functions Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom
• Backup Mode USB Device/Internal SATA burner

• Ethernet RJ-45 port (10/100M)
• Network Functions HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, SNMP, P2P
• Max. User Access 128 users
• Smart Phone iPhone, iPad, Android, Windows Phone

• Internal HDD 1 SATA port, up to 4TB
• Auxiliary Interface
• USB Interface 2 ports(1 Rear), USB2.0
• RS485 1 port, For PTZ Control

• Power Supply DC12V/2A
• Power Consumption 10W(without HDD)
• Working Environment -10°C ~+55°C / 10%~90%RH / 86~106kpa
• Dimension(W×D×H) Mini 1U, 325mm×255mm×55mm / 12.8" x 10" x 2" inches
• Weight 1.5KG(without HDD)
