Qube 8-Channel MUX Network Video Recorder/ 1080P/ 8MP

More TVR Recorder Options, Click here

Features:

• Analog Video Input: 4CH, BNC
• IP Video Input: 2-ch(only IP up to 6ch),each channel up to 4K
• Supported Analog Camera Types:
  • Support AHD input:
    • 8MP@15fps(channel1-channel2)
    • 5MP@20fps
    • 4MP@30fps
    • 3MP@30fps (channel1 –channel2)
    • 1080P@30fps
    • 720P@60fps
  • Support TVI input:
    • 8MP@15fps(channel1-channel2)
    • 5MP@20fps
    • 4MP@30fps
    • 3MP@20fps (channel1 – channel2)
    • 1080P@30fps
    • 720P@60fps
  • Support CVI input:
    • 8MP@15fps(channel1-channel2)
    • 5MP@20fps
    • 4MP@30fps
    • 1080P@30fps
    • 720P@30fps
  • Support CVBS input
• Audio Input: 1-CH, RCA
• Two-Way Audio: 1-CH, RCA
• Channel Associated Audio: 1-CH, RCA

• Incoming Bandwidth: 56Mbps
• Outgoing Bandwidth: 64Mbps
• Remote Users: 128
• Protocols: TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE

• CVBS Output: 1-CH, BNC
• VGA Output:
  • 1920x1080p/60Hz,
  • 1920x1080p/50Hz,
  • 1600x1200/60Hz,
  • 1280x1024/60Hz,
  • 1280x720/60Hz,
  • 1024x768/60Hz
• HDMI Output:
  • 1920x1080p/60Hz,
  • 1920x1080p/50Hz,
  • 1600x1200/60Hz,
  • 1280x1024/60Hz,
  • 1280x720/60Hz,
  • 1024x768/60Hz
• Audio Output: 1-CH, RCA
• Synchronous Playback: 8-CH

• Recording Resolution: 8MP Lite/5MP Lite/4MP Lite /3MP/1080P/960P/720P/960H/4CIF/CIF
• Recording Frame Rate:
  • Main stream:
    • 8MP Lite@8fps（channel1-channel2）
    • 720P@30fps
    • 2MP@15fps
    • 3MP@15fps(channel1 – channel2)
    • 4MP Lite@15fps
    • 5MP Lite@12fps
  • Sub stream:
  • D1@30fps(Max)

• SATA: 1 Sata Interface
• Capacity: Up to 6TB for each HDD

• Network Interface: 1RJ45 10M/100M self-adaptive Ethernet Interface
• USB Interface: Rear panel：2 x USB2.0
• Serial Interface: 1xRS485

• Power Supply: 12V DC
• Power Consumption: ≤ 8 W(without HDD)
• Working Environment: -10°C ~ + 55°C ( +14°F ~ +131°F ), Humidity ≤ 90% RH(non-condensing)
• Dimension: 260mm ×240mm× 46mm (10.2" × 9.4"×1.8")
• Weight (w/out HDD): ≤1.1 Kg ( 4.19lb )
