Qube Tvi Ptz SWAIN / CMOS / 23X ZOOM / 100M IR / OUTDOOR / 1080P CCTV Camera

Daytime Demo:

Nighttime Demo:

• 1/2.8'' Progressive Scan CMOS
• 1920×1080
• 23X Optical Zoom
• DWDR
• Up to 100m IR distance
• 3D intelligent positioning function
• Turbo HD and CVBS dual output

Camera

• Image Sensor: | 1/2.8" Progressive Scan CMOS
• Effective Pixels: | 1920(H)x1080(V)
• Signal System: | NTSC
• Minimum Illumination: | Color: 0.05Lux@( F1.4,AGC ON); B/W: 0.005Lux@( F1.4,AGC ON), 0 Lux with IR
• White Balance: | Auto / Manual / ATW / Indoor / Outdoor
• AGC: | Auto/Manual
• BLC: | ON/OFF
• WDR: | Support
• Shutter Time: | 1-1/10,000s
• Day& Night: | ICR
• Digital Zoom: | 16X
• Privacy Masking: | 8 privacy masks programmable
• Auto Focus: | Auto / Semi-automatic / Manual

• Focal Length: | 4-92.0mm, 23x
• Zoom Speed: | Approx.3s(Optical Wide~Tele)
• Angle of View: | 49-2.2 degree(Wide-Tele)
• Minimum Working Distance: | 10~1,000mm(Wide~Tele)
• Aperture Range: | F1.4-F3.5

• Pan Range: | 360°endless
• Pan Speed: | Pan Manual Speed: 0.1°~80°/s, Pan Preset Speed: 80°/s
• Tilt Range: | -15°-90° (Auto Flip )
• Tilt Speed: | Tilt Manual Speed: 0.1°~80°/s, Tilt Preset Speed: 80°/s
• Proportional Zoom: | Rotation speed can be adjusted automatically according to zoom multiples
• Number of Preset: | 256
• Patrol: | 8 patrols, up to 32 presets per patrol
• Pattern: | 4 patterns, with the total recording time not less than 10 minutes
• Power loss recovery: | Support
• Park Action: | Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan
• PTZ Position Display: | ON/OFF
• Freeze Frame: | Support

• IR irradiation distance: | 100m
• IR irradiation angle: | Adjustable by zoom

• RS-485 Protocols: | Pelco-P, Pelco-D, self-adaptive
• Menu Language: | English
• Power Supply: | 12V DC
• Power Consumption: | Max.18W
• Working Temperature/Humidity: | -30 °C-65°C(-22°F-149°F)
• Protection Level: | IP66 standard (outdoor dome)
• TVS 4,000V lightning protection, surge protection and voltage transient protection
• Mounting: | Various mounting modes optional
• Dimensions: | Φ164.5(mm)×295(mm)
• Weight (approx.): | 2Kg (4.41Ibs)
