Qube Wireless NVR CCTV Kit 4ch 1080P Indoor/Outdoor Package 2

Please call our Stores to inquire about qualified credit card.

NVR Specification

• Model NVR-4CH-WF

• Main Processor Dual-core embedded processor
• Operating System Embedded LINUX

• IP Camera: Input 4 channel
• Two-way: Talk 1 channel Input, 1 channel Output, RCA

• Interface: 1 HDMI, 1 VGA
• Resolution: 1920×1080, 1280×1024, 1280×720, 1024×768
• Display: Split 1/4
• OSD Camera: title, Time, Video loss, Camera lock, Motion detection, Recording

• Compression: H.264/MJPEG
• Resolution: 5Mp(2560×1920)/3Mp(2048×1536)/1080P(1920×1080)/720P(1280×720)/D1 (704×576/704×480)
• Record Rate: 80Mbps
• Bit Rate: 48~ 8192kbps
• Record Mode: Manual, Schedule(Regular(Continuous), MD, Alarm), Stop
• Record Interval: 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec

• Trigger Events: Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer & Screen tips
• Video Detection: Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank

• Sync: Playback 1/4
• Search Mode: Time/Date, Alarm, MD & Exact search (accurate to second), Smart search
• Playback Function: Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom
• Backup Mode: USB Device/Network/Internal SATA burner

• Ethernet: 1 RJ-45 port (10/100Mbps)
• Wireless Network: Built-in WiFi module, 2 WiFi Antenna
• Network: Function HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, Alarm Server, IP Search(Support Qube IP camera, DVR, NVS and etc.)
• Max. User Access: 128 users
• Smart Phone iPhone, iPad, Android, Windows Phone

• Internal HDD: 1 SATA port, up to 4TB

• USB 2: ports (2 Rear),USB2.0

• Power Supply: DC12V/2A
• Power Consumption: 10W(without HDD)
• Working Environment: -10°C~+55°C / 10%~90%RH / 86~106kpa
• Dimension: (W×D×H) Smart 1U, 205mm×205mm×40mm / 8.0" x 8.0" x 1.5" inches
• Weight: 0.5KG(without HDD)

CCTV Specification

• Model Finch

• Image Sensor : 1/3”2Megapixel progressive scan CMOS
• Effective Pixels: 2048(H)x1536(V)
• Scanning System: Progressive
• Electronic Shutter: Speed Auto/Manual 1/3(4)~1/10000
• Min. Illumination: Color: 0. 1Lux/F1.6; 0Lux/F1.6 (IR on)
• S/N Ratio: More than 50dB
• Video Output: N/A

Camera Features

• Max. IR LEDs Length: 30m
• Day/Night: Auto(ICR) / Color / B/W
• Backlight Compensation: BLC /HLC /DWDR
• White Balance: Auto/Manual
• Gain Control: Auto/Manual
• Noise Reduction: 2D
• Privacy Masking: Up to 4 areas

• Focal Length: 3.6mm
• Max Aperture F1.8(F1.6)
• Focus Control: Manual
• Angle of View: H: 72°(44°)
• Lens Type: Fixed lens
• Mount Type: Board-in Type

• Compression: H.264H/H.264B/H.264/ MJPEG
• Resolution: 1080P(1920×1080)/720P(1280×720)/D1(704×576/704×480) /CIF(352×288/352×240)
• Frame Rate Main Stream: 1080P(1 ~ 25/30fps)
• Sub Stream: D1/CIF(1 ~ 25/30fps)
• Bit Rate: H.264H: 16K ~ 8192Kbps

• Compression: N/A
• Interface: N/A

• Ethernet: RJ-45 (10/100Base-T)
• Wi-Fi Wi-Fi: (IEEE802.11b/g/n)
• Wi-Fi Range: 50m(open field)
• Protocol: IPv4/IPv6, HTTP, HTTPS, TCP/IP, UDP, UPnP, ICMP, IGMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS
• Compatibility: ONVIF, CGI
• Max. User Access: 20 users
• Smart Phone iPhone, iPad, Android, Windows Phone

• Memory Slot: N/A
• RS485: N/A
• Alarm: N/A
• PIR Sensor Range: N/A

• Power Supply: DC12V
• Power Consumption: <7W
• Working Environment: -30°C~+50°C, Less than 95%RH
• Ingress Protection: IP66
• Vandal Resistance: N/A
• Dimensions: Φ70mm×66mm×155mm / 2.7" x 2.5" x 6.1" inches
• Weight: 0.42Kg
